GENERAL:

The 1160 Resort has been developed to meet the ever demanding needs of modern-day charter operations. Keeping things simple, the Resort offers a low maintenance high capacity 38ft catamaran at an entry level price. Perfect for any day charter operation around the world!

EXTERIOR / LAMINATE:

• Finish: Full female moulded hulls & decks, exterior gelcoat finish with moulded-in non-slip surface on deck areas
• Hull Laminate: Infused Vinyl Ester (Modified epoxy) resin laminate of the entire hull laminate
• Hull Core Material: PVC closed cell foam core
• Deck Laminate: Vacuum formed polyester resin resin laminate
• Deck Core Material: PVC closed cell foam core
• General Laminate: Vacuum formed polyester resin resin laminate
• General Core Material: PVC closed cell foam core
• Laminate specifications are certified to International CE standards

MAST/BOOM/SAILS:

• Clear anodised aluminium mast and boom. Single Spreader, 7/8 rig
• Standing Rigging:

– Forestay 3/8 (10mm) 1 x 19 Dyform wire

– Sidestays 3/8 (10mm) 1 x 19 Dyform wire

– Diamonds 5/16 (8mm) 1 x 19 Stainless Steel wire

• Halyards:

– Main halyard: 12mm Spectra rope : Heavy duty shackle

– Jib halyard: 8mm Spectra rope. Heavy duty shackle

– Topping lift: 8mm rope. Heavy duty shackle

– Boom outhaul: 10mm Spectra

• Single line reefing, run to helm. Three reefing points with 2 reef lines:

– Reef 1&3: 10mm rope. Leech/Clew blocks and snap shackle

– Reef 2: 10mm rope. Heavy duty shackle

• Sheets:

– Main sheet: 10mm rope

– Main traveller control:  8mm rope

– Jib sheet: 10mm rope

• Reefing lines and sheets to be lead back to cockpit through turning blocks and rope clutches
• Fully battened mainsail. Triple stitched reinforced construction. Leach adjustable batten end caps. Fibreglass sail battens
• Mainsail cover with integrated lazy jack system

DECK EQUIPMENT:

• 6 x Docking cleats. Each side : bow, stern & amidships
• 1 x Heavy duty mooring cleat on forward walkway
• Sheet winches : 2 x 45ST – 2 speed self tailing
• Stanchions/Rails: High quality stanchions, bow rails and stern rails with 3 life-lines.  With 700mm high lifelines to meet CE requirements.
• 2 x transom access gates with pelican hook releases
• 2 x side access gates with pelican hook releases
• Aft swim ladder: folding stainless aft swim ladder

FORWARD BEAM, CATWALK AND TRAMPOLINES:

• Carbon reinforced fwd beam
• Pelican striker and adjustable cable
• 1 x Mooring plate above foredeck
• 2 x Anchor roller under deck. Permanent stowage position for 45lb Plough (CQR/Delta type) anchor  (cheeks 75mm high)
• Catwalk in pvc foam-sandwich fibreglass
• Light weight plastic coated open netted trampolines

AFT BEAM AND DECK:

• Curved mainsheet track and continuous line traveller control system
• Composite seats behind aft beam
• Full width hard top over cockpit

STEERING SYSTEM:

• Central helm station
• 32” stainless steel steering wheel

INTERIOR FINISH:

• Flowcoat interior finish
• Lightweight cupboard doors and trimmings

 GALLEY:

• Spacious galley with scratch resistant counter surfaces
• Double bowl stainless steel sink
• Pressure fresh water system
• Top loading Ice Box
• Under bench storage

PORT HEAD:

• Light weight pvc foam cored door
• Manual toilet. Discharge via holding tank
• Holding tank built in. Discharge pump out by shore station or directly overboard 130L
• Pipes, skin fittings and sea-cocks are easily accessible and to meet survey requirements
• Vanity basin with pressure water
• Large quantity cupboards

LIGHTING/ELECTRICAL SYSTEM:

• High quality DC electrical switch panel with circuit breakers, LED indicator lights and voltage display
• Marine grade tinned electrical wiring with extensive use of heat sealed connectors
• Batteries x 3 comprising: House System (260 amp hrs) : 2 x 130 amp hr heavy duty batteries One engine cranking battery – 130 amp hr heavy duty battery
• 230amp heavy duty isolation switch
• 12 V lighting : Numerous 12V interior lamps and courtesy lights throughout including recessed lights in cockpit
• 4 x 12V Outlets
• CE approved navigation lights. Port & Starboard mounted on bow rails
• Deck floodlight mounted on spreaders
• Mast head anchor / riding light
• 2 x 120W Solar panels and solar regulator

PLUMBING / FRESH WATER TANKS:

• Pressure water system with water to galley and bathrooms
• Fresh water tank: 430 litres ( 112 gallons). Remote deck filler
• Electric fresh water pump
• Electric bilge pumps (2) with controls integral with master battery switch panel
• Manual bilge pumps (2) in each hull
• New Marelon through-hull fittings to CE/ISO standard
• Manual toilet in head

 ENGINES:

• Twin Yamaha 25hp 20” engines. Mounted under aft seating
• 5” leg extensions added to engines to reduce cavitation
• Remote electric key start with electric tilt fitted
• Dual engine controls at helm station
• 200l fuel tank

NAVIGATION:

• Steering compass

ANCHORING / MOORING:

• Primary anchor is 45 lb Delta anchor type with 15 mtrs x 8mm short link galvanised chain and 40 mtrs x 16mm triple braid anchor warp
• Primary anchor is stored in a specially designed anchor roller under the forward beam
• 3 x PVC Inflatable Fenders
• 3 x Mooring lines (each 15 mtrs x 14mm)

 ANTIFOULING / STRIPING:

• Epoxy barrier coat plus 2 coats of high quality black antifouling bottom paint
• Seawind 1160 Resort decal on each hull and stern

DISCLAIMER: The specifications above may change at Seawind Catamaran’s discretion.
